Configuration
Basic configurations
8.5
l
8.5−82
EDSVS9332P EN 5.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C1710
g
−2147483647
{1}
2147483647 BCD2
See system
manual
(extension)
1 OUTPUT
SIGNAL
Display of output signal
2 BCD RESULT
Display of the output signal
after the evaluation with
C1703/C1704 and C1705
C1711 BCD2 CODE
141
11
{1}
2000 BCD2
Code
C1712 BCD2
SUBCODE
0
0
{1}
255 BCD2
Subcode
C1713 BCD2
NUMERATOR
1
0
{1}
100000 BCD2
Numerator
C1714 BCD2
DENOMINATO
R
0.0001 0.0001
{0.0001}
100000.0000 BCD2
Denominator
C1715 BCD2 OFFSET
0
0
{1}
1000000000 BCD2
Offset
C1716 BCD MODE
0
0
1
Without acceptance signal
With acceptance signal
BCD2
Mode
C1717 BCD DELAY
10
0
{1 ms}
255 BCD2
Deceleration
C1718
s
® selection list 2 BCD2
Configuration of digital input
signals
See system
manual
(extension)
1 BCD2−READ
1000
FIXED0
2 BCD2−DATA1
1000
FIXED0
3 BCD2−DATA2
1000
FIXED0
4 BCD2−DATA3
1000
FIXED0
5 BCD2−DATA4
1000
FIXED0
6 BCD2−LOAD
1000
FIXED0
7 BCD2−BUSY−IN
1000
FIXED0
8 BCD2−FAIL−IN
1000
FIXED0
C1719
g
0
1 BCD2
Display of digital input signals
1 BCD2−READ
2 BCD2−DATA1
3 BCD2−DATA2
4 BCD2−DATA3
5 BCD2−DATA4
6 BCD2−LOAD
7 BCD2−BUSY−IN
8 BCD2−FAIL−IN
