IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0017 FCODE (QMIN) 50 −16000 {1 rpm} 16000 FCODE (Q
min
)
Switching threshold n
is
< n
x
n
act
< C0017 activates the
comparator output CMP1−OUT
C0018 FCHOP 1 Chopper frequency f
chop
0 16/8 kHz Noise−optimised operation with
automatic changeover to 8 kHz
1 8 kHz sine Noise optimised operation
2 16 kHz sine
C0019 THRESH
NACT=0
0 0 {1 rpm} 16000 Speed threshold for standstill
message
Status word bit DCTRL−NACT=0
C0021 SLIPCOMP 0.00 0.00 {0.01 %} 20.00 Slip compensation
l Only active with sensorless
control below the value of
C0291
C0022 IMAX
CURRENT
à 0 {0.01 A} 1.50 I
N
Limit current I
max
à Depends on C0086
l Change of C0086 resets
value to the assigned factory
setting (1.5×Imotor)
C0025
s
FEEDBACK
TYPE 10 Feedback
Input of the encoder specified
on the nameplate of the Lenze
motor:
C0025 automatically changes
C0420, C0490, C0495
0 COMMON C0420, C0490 or C0495 has
been changed subsequently
1 Without feedback Control without feedback
system (sensorless control, SSC)
10 RSx (resolver) The resolver is designated with
RSxxxxxxxx.
If a resolver is selected, the
rotor displacement angle in
C0058 is set to −90°.
110 IT−512−5V Incremental encoder with TTL
level
111 IT−1024−5V
112 IT−2048−5V
113 IT−4096−5V
210 IS−512−5V SinCos encoder
211 IS−1024−5V
212 IS−2048−5V
213 IS−4096−5V
309 AS−128−8V (SKS) Single−turn SinCos encoder with
RS485 interface Co. Stegmann
(absolute value encoder)
l Enter the supply voltage in
C0421.
310 AS−512−8V (SCS)
311 AS−1024−8V SRS
409 AM−128−8V (SKM) Stegmann multi−turn SinCos
encoder with RS485 interface
(absolute value encoder)
l Enter the supply voltage in
C0421.
410 AM−512−8V (SCM)
411 AM−1024−8V (SRM)
If an absolute value encoder is
selected, an SD7 trip is
triggered.
