Commissioning
Automatic control parameter identification
Important notes
6
6.15
6.15.1
l
6.15−1 EDSVS9332P EN 5.0−07/2013
6.15 Automatic control parameter identification
6.15.1 Important notes
(
Stop!
ƒ A control parameter identification can only be carried out if
the drive is not exposed to external torques. In the event of
overhauling loads, for instance, a motion must not be
activated through the function.
ƒ Release the brake (if mounted) before executing the control
parameter identification.
ƒ In order to comply with the number of revolutions, a brake
resistor or a regenerative power supply unit and a constant
moment of inertia are required.
– A major change to the Lenze setting in the "Limitation" field
(C1182 C1185) may cause deviations during the
identification of the distance parameters and thus can cause
deviations with regard to the controller setting.
ƒ The motion to be carried out by the control parameter
identification must be set in a way that even the slowest
rotating element of the drive train is still moving significantly.
ƒ The controller has to be inhibited (X5/28 = LOW).
ƒ The drive has to be at standstill.
)
Note!
If the requirements are not met, the control parameter
identification is not executed and an error code is set.
(
¶ 6.15−4)
ƒ In the case of a reactivation, the error is reset and the function
is initialised.
6.15.2 Description
How to open the dialog box (device description, from version 8.0):
1. Open the "short setup" menu.
2. Double−click the "DIALOG control parameter identification".
Requirements for the
activation
