Electrical System
9.68 Model 644E-42/944E-42 Rev. 6/04
9.8.23 Optional Worklight Electrical Schematic Legend
Wire No. Page Gauge Color From - Function - To
EG8
9.69
12 BLK Splice 245 To Ground Buss Bar
LP5A 18 LT BLU Cab Lighting, 4 Pin Female, Connector (Pin C) To Splice 230
WL4 12 RED/WHT Work/Roadlight Fuse (F24) (Pin X) To Splice 225
WL4A 16 RED/WHT Worklight Switch, 8 Pin Female, Connector (Pin 8) To Splice 225
WL4B 14 RED/WHT Worklight Switch, 8 Pin Female, Connector (Pin 2) To Splice 225
WL4C 14 RED/WHT Worklight Switch, 8 Pin Female, Connector (Pin 5) To Splice 225
WL5 14 LT BLU Worklight Switch, 8 Pin Female, Connector (Pin 3) To Splice 230
WL5A 14 LT BLU Worklight Bulkhead, Female, Connector (Pin A) To Splice 230
WL5B 14 LT BLU Worklight Bulkhead, Male, Connector (Pin A) To Splice 235
WL5C 14 LT BLU Boom Worklight, Male, Connector (Pin A) To Splice 235
WL5D 14 LT BLU Left Front Worklight (Pin P) To Splice 235
WL5E 14 LT BLU Right Front Worklight (Pin P) To Splice 235
WL6 14 YEL
Worklight Switch, 8 Pin Female, Connector (Pin 6)
To Worklight Bulkhead, Female, Connector (Pin B)
WL6A 14 YEL Worklight Bulkhead, Male, Connector (Pin B) To Splice 240
WL6B 14 YEL Left Rear Worklight (Pin P) To Splice 240
WL6C 14 YEL Right Rear Worklight (Pin P) To Splice 240
WLG5 14 BLK Boom Worklight, Male, Connector (Pin B) To Splice 245
WLG6 14 BLK Left Front Worklight (Pin N) To Splice 245
WLG7 14 BLK Right Front Worklight (Pin N) To Splice 245
WLG8 16 BLK Worklight Switch, 8 Pin Female, Connector (Pin 7) To Cab Ground Stud
WLG9 14 BLK Left Rear Worklight (Pin N) To Splice 245
WLG10 14 BLK Right Rear Worklight (Pin N) To Splice 245
