2.15 Model 644E-42/944E-42 Rev. 6/04
General Information, Specifications and Maintenance
2.5.7 Electrical System
Description 644E-42 944E-42
Battery:
Type, Rating 12 VDC, Negative (-) Ground, Maintenance Free
Standard Vehicle Quantity 1 2
Cold Start Option Quantity (644E-42 Only) 2 N/A
Standard Vehicle Reserve Capacity 850 Cold Cranking amps @ 0° F (-18° C)
With Cold Start Option Reserve Capacity 1700 Cold Cranking amps @ 0° F (-18° C)
Group/Series Group 27
Alternator 12V/65 amps 12V/65 amps
Fuses - Standard Blade Style:
F1 - Open Cab Vehicle Main 40 amps 40 amps
F2 - Ignition Control 15 amps 15 amps
F3 - Transmission 15 amps 15 amps
F4 - Fuel Solenoid 7.5 amps 7.5 amps
F5 - Ignition Power 20 amps 20 amps
F6 - Back-Up Alarm/Horn 10 amps 10 amps
F7 - Stability Circuit 10 amps 10 amps
F8 - Dash 10 amps 10 amps
F9 - Open — —
F10 - Auxiliary Hydraulics 7.5 amps 7.5 amps
F11 - Open — —
F12 - Open — —
F13 - Open — —
F14 - ECM Indicator Light (944E-42 Only) N/A 3 amps
F15 - Closed Cab Main (Option) 40 amps 40 amps
F16 - Front Wiper 10 amps 10 amps
F17 - Heater Fan (Option) 25 amps 25 amps
F18 - Roof Wiper (Option) 7.5 amps 7.5 amps
F19 - Rear Wiper (Option) 7.5 amps 7.5 amps
F20 - Beacon/Strobe (Option) 10 amps 10 amps
F21 - Brake Lights (Option) 7.5 amps 7.5 amps
F22 - Headlights (Option) 20 amps 20 amps
F23 - Turn Signals (Option) 15 amps 15 amps
F24 - Worklights/Roadlights (Option)
Worklights Only (Option)
20 amps
30 amps 20 amps
30 amps
