9.39 Model 644E-42/944E-42 Rev. 6/04
Electrical System
EG3
9.49 or
9.51
16 BLK Splice 100 To Ground Buss Bar
EG4
9.49 or
9.51
16 BLK Back-Up Alarm, Female, Connector (Pin B) To Splice 90
EG5
9.49 or
9.51
16 BLK Splice 80 To Splice 90
EG6
9.49 or
9.51
16 BLK Splice 110 To Ground Buss Bar
9.54 6 RED 125 Amp Fuse To Grid Heater Relay 1 (Pin 2) (944E-42 Only)
FJ1
9.48 or
9.50
Bare Metal Connector Transmission Fuse (F3) (Pin 3) To Fuel Solenoid Fuse (F4) (Pin 4)
FJ2
9.48 or
9.50
Bare Metal Connector Fuel Solenoid Fuse (F4) (Pin 4) To Ignition Fuse (F5) (Pin 5)
FJ3
9.48 or
9.50
Bare Metal Connector Ignition Fuse (F5) (Pin 5) To Back-Up Alarm/Horn Fuse (F6) (Pin 6)
FJ4
9.48 or
9.50
Bare Metal Connector Back-Up Alarm/Horn Fuse (F6) (Pin 6) To Stabilizer Fuse (F7) (Pin 7)
FJ5
9.48 or
9.50
Bare Metal Connector Stabilizer Fuse (F7) (Pin 7) To Dash Panel Fuse (F8) (Pin 8)
FJ6
9.48 or
9.50
Bare Metal Connector Dash Panel Fuse (F8) (Pin 8) To Open (F9) (Pin 9)
FJ7
9.48 or
9.50
Bare Metal Connector Open (F9) (Pin 9) To Auxiliary Hydraulic Fuse (F10) (Pin 10)
FJ8
9.48 or
9.50
Bare Metal Connector Auxiliary Hydraulic Fuse (F10) (Pin 10) To Open Fuse (F11) (Pin 11)
FJ9
9.48 or
9.50
Bare Metal Connector Open Fuse (F11) (Pin 11) To Open Fuse (F12) (Pin 12)
FJ10
9.48 or
9.50
Bare Metal Connector Open Fuse (F12) (Pin 12) To Open (F13) (Pin 13)
FJ11
9.48 or
9.50
Bare Metal Connector Open (F13) (Pin 13) To ECM Indicator Light Fuse (F14) (Pin 14)
FJ12
9.48 or
9.50
Bare Metal Connector
Optional Front Wiper Fuse (F16) (Pin 16)
To Optional Heater Fan Fuse (F17) (Pin 17)
FJ13
9.48 or
9.50
Bare Metal Connector
Optional Heater Fan Fuse (F17) (Pin 17)
To Optional Skylight Wiper Fuse (F18) (Pin 18)
FJ14
9.48 or
9.50
Bare Metal Connector
Optional Skylight Wiper Fuse (F18) (Pin 18)
To Optional Rear Wiper Fuse (F19) (Pin 19)
FJ15
9.48 or
9.50
Bare Metal Connector
Optional Lighting Power Relay Fuse (F20) (Pin 20)
To Optional Lighting Brake Switch Fuse (F21) (Pin 21)
FJ16
9.48 or
9.50
Bare Metal Connector
Optional Lighting Brake Switch Fuse (F21) (Pin 21)
To Optional Headlights Fuse (F22) (Pin 22)
FJ17
9.48 or
9.50
Bare Metal Connector
Optional Headlights Fuse (F22) (Pin 22)
To Optional Lighting Hazard Switch Fuse (F23) (Pin 23)
FJ18
9.48 or
9.50
Bare Metal Connector
Optional Lighting Hazard Switch Fuse (F23) (Pin 23)
To Optional Lighting Worklight Switch Fuse (F24) (Pin 24)
FJ19
9.48 or
9.50
Bare Metal Connector
Optional Lighting Main Fuse (F25) (Pin 25)
To Optional Air Conditioning Condenser Fan Fuse (F26) (Pin 26)
FJ20
9.48 or
9.50
Bare Metal Connector Optional Air Conditioning Condenser Fan Fuse (F26) (Pin 26) To Open (F27) (Pin 27)
FJ21
9.48 or
9.50
Bare Metal Connector Open (F27) (Pin 27) To Open (F28) (Pin 28)
FR1 9.52 12 RED
Fuel Shutoff Relay (Pin 1) To 12V Buss Bar
(644E-42 SN 20118 & Before, 0160002519 thru 0160003689 and 944E-42 Only)
FR2 9.52 12 WHT
Fuel Shutoff Relay (Pin 2)
To Fuel Shutoff Solenoid, 3 Pin Female, Connector (Pin B)
(644E-42 SN 20118 & Before, 0160002519 thru 0160003689 and 944E-42 Only)
FR3 9.52 14 BLU/ORG
Engine Start Relay (Pin 3) To Fuel Shutoff Relay (Pin 3)
(644E-42 SN 20118 & Before, 0160002519 thru 0160003689 and 944E-42 Only)
Wire No. Page Gauge Color From - Function - To
These wires are not part of a wire harness. Refer to the appropriate Parts Manual for part number information.
