2.3 Model 644E-42/944E-42 Rev. 6/04
General Information, Specifications and Maintenance
2.1 644E-42 / 944E-42 COMPONENT
TERMINOLOGY
To understand the safety, operation and maintenance
information presented in this manual, it is necessary that
the operator/mechanic be familiar with the name and
location of the major assemblies on this vehicle. The
following illustration identifies the components that are
referred to throughout this manual.
MU4441
Operator’s
Protective
Structure
Stabilizer
Cylinder
Boom
Assembly
Hydraulic
Oil Tank
Carriage
Assembly
Engine
Compartment
Frame Sway
Cylinder
Slave
Cylinders (2)
(1 Not Visible) Lift/Lower
Cylinder
