Electrical System
9.36 Model 644E-42/944E-42 Rev. 6/04
BA3
9.48 or
9.50
12 RED/BLU Ignition Control Fuse (F2) (Pin 2) To Ignition Relay (Pin 30)
BA4
9.48 or
9.50
12 RED/GRN Ignition Relay (Pin 87) To Transmission Fuse (F3) (Pin 3)
BB1
9.52,
9.53 or
9.54
10 RED Power Bulkhead, 3 Pin Female, Connector (Pin B) To 12V Buss Bar
BB1A
9.48 or
9.50
10 RED
Power Bulkhead, 3 Pin Male, Connector (Pin B)
To Optional Closed Cab Power Fuse (F15) (Pin 15)
BC1
9.52,
9.53 or
9.54
10 RED Power Bulkhead, 3 Pin Female, Connector (Pin C) To 12V Buss Bar
BC1A
9.48 or
9.50
10 RED
Optional Lighting Main Fuse (F25) (Pin 25)
To Power Bulkhead, 3 Pin Male, Connector (Pin C)
BN 9.54 16 BLK
Battery 2, Negative (-) Terminal
To Engine Control Module, 9 Pin Male, Diagnostic Connector, P7 (Pin A) (944E-42 Only)
BNE 9.54 16 BLK
Battery 2, Negative (-) Terminal
To Engine Control Module, 23 Pin Female, Engine Connector, P1 (Pin E) (944E-42 Only)
BNF 9.54 16 BLK
Battery 2, Negative (-) Terminal
To Engine Control Module, 23 Pin Female, Engine Connector, P1 (Pin F) (944E-42 Only)
BNH 9.54 16 BLK
Battery 2, Negative (-) Terminal
To Engine Control Module, 23 Pin Female, Engine Connector, P1 (Pin H) (944E-42 Only)
BNP 9.54 14 BLK
Battery 2, Negative (-) Terminal
To Engine Control Module, 23 Pin Female, Engine Connector, P1 (Pin P) (944E-42 Only)
BNW 9.54 14 BLK
Battery 2, Negative (-) Terminal
To Engine Control Module, 23 Pin Female, Engine Connector, P1 (Pin W) (944E-42 Only)
BP1
9.48 or
9.50
16 RED/GRN Vehicle Bulkhead, 15 Pin Female, Connector (Pin A5) To Splice 50
BP1A
9.49 or
9.51
16 RED/GRN
Boom Proximity Sensor, 3 Pin Female, Connector (Pin A)
To Vehicle Bulkhead, 15 Pin Male, Connector (Pin A5)
BP2
9.49 or
9.51
16 BLK
Boom Proximity Sensor, 3 Pin Female, Connector (Pin C)
To Vehicle Bulkhead, 15 Pin Male, Connector (Pin B2)
BP3
9.49 or
9.51
16 TAN
Boom Proximity Sensor, 3 Pin Female, Connector (Pin B)
To Vehicle Bulkhead, 15 Pin Male, Connector (Pin B1)
BP3A
9.48 or
9.50
16 TAN Vehicle Bulkhead, 15 Pin Female, Connector (Pin B1) To Boom Switch Relay (Pin 85)
BPB 9.54 16 RED/WHT
7.5 amp Mini Fuse VESPAK Connector P5 (Pin B)
To Engine Control Module, 23 Pin Female, Engine Connector, P1 (Pin B) (944E-42 Only)
BPB1 9.54 16 RED/WHT
Battery 2, Positive (+) Terminal
To 7.5 amp Mini Fuse VESPAK Connector P5 (Pin A) (944E-42 Only)
BPC 9.54 16 RED/WHT
7.5 amp Mini Fuse VESPAK Connector P5 (Pin D)
To Engine Control Module, 23 Pin Female, Engine Connector, P1 (Pin C) (944E-42 Only)
BPC1 9.54 16 RED/WHT
Battery 2, Positive (+) Terminal
To 7.5 amp Mini Fuse VESPAK Connector P5 (Pin C) (944E-42 Only)
BPD 9.54 16 RED/WHT
7.5 amp Mini Fuse VESPAK Connector P5 (Pin F)
To Engine Control Module, 23 Pin Female, Engine Connector, P1 (Pin D) (944E-42 Only)
BPD1 9.54 16 RED/WHT
Battery 2, Positive (+) Terminal
To 7.5 amp Mini Fuse VESPAK Connector P5 (Pin E) (944E-42 Only)
BPG
9.48 or
9.50
16 BLK Vehicle Bulkhead, 15 Pin Female, Connector (Pin B2) To Splice 85
BPL1 9.54 16 RED/GRN
10 amp Mini Fuse VESPAK Connector P6 (Pin F)
To Engine Control Module, 9 Pin Male, Diagnostic Connector, P7 (Pin B) (944E-42 Only)
BPL2 9.54 16 RED/GRN
Battery 2, Positive (+) Terminal
To 10 amp Mini Fuse VESPAK Connector P6 (Pin E) (944E-42 Only)
BPM 9.54 14 RED/GRN
10 amp Mini Fuse VESPAK Connector P6 (Pin B)
To Engine Control Module, 23 Pin Female, Engine Connector, P1 (Pin M) (944E-42 Only)
BPM1 9.54 14 RED/GRN
Battery 2, Positive (+) Terminal
To 10 amp Mini Fuse VESPAK Connector P6 (Pin A) (944E-42 Only)
Wire No. Page Gauge Color From - Function - To
These wires are not part of a wire harness. Refer to the appropriate Parts Manual for part number information.
