Lull 944E-42 Service Manual - Manual (Page 30)

General Information, Specifications and Maintenance
2.14 Model 644E-42/944E-42 Rev. 6/04
2.5.5 Performance Specifications
Note: Performance criteria is based on full throttle engine speed unless otherwise specified or not applicable.
2.5.6 Hydraulic Cylinder Performance Specifications
Note: Vehicle with no load, engine at full throttle, hydraulic oil above 130° F (54° C) minimum, engine at operating
temperature
.
Travel Speed (Standard Tires, No Load) 644E-42 944E-42
First Gear 0 - 3.5 mph (0-5,6 km/hr) 0 - 3.5 mph (0-5,6 km/hr)
Second Gear 0 - 6.0 mph (0-9,7 km/hr) 0 - 6.0 mph (0-9,7 km/hr)
Third Gear 0 - 14 mph (0-23 km/hr) 0 - 14 mph (0-23 km/hr)
Fourth Gear 0 - 20 mph (0-32 km/hr) 0 - 20 mph (0-32 km/hr)
Function Approximate Times
Boom Extend 11 to 15 seconds
Boom Retract 13 to 17 seconds
Boom Lift Retracted 11 to 15 seconds
Boom Lower Retracted 11 to 15 seconds
Attachment Tilt - UP 2.5 to 4.5 seconds
Attachment Tilt - DOWN 3 to 5 seconds
Transfer Carriage Forward with Boom Retracted and Level 9 to 14 seconds
Transfer Carriage Rearward with Boom Retracted and Level 9 to 13 seconds
Frame Sway Left to Right with Boom Down 12 to 17 seconds
Frame Sway Left to Right with Boom Above 40 ° and Emergency Brake Engaged 28 to 37 seconds
Frame Sway Right to Left with Boom Down 12 to 17 seconds
Frame Sway Right to Left with Boom Above 40 ° and Emergency Brake Engaged 30 to 36 seconds
