6.4.4
Autopan, Aux, Focus, Iris
All these functions can be loaded by pressing the specific keys in the control menu area of the Main menu (see
§ 4.4 – Control menu area, page 45).
Refer to § 9.1 – Functions assigned to the most common graphics keys, page 164 e § 9.2.1 – Dome, page 165
to check which functions are available for the dome.
6.4.4.1
Autopan
The path to be taken is set up using the Special codes. Activating Zoom Tele and/or Zoom Wide
does not stop any dome movement in progress.
6.4.4.2
Focus
When AUTOFOCUS is activated, pressing the FOCUS FAR and FOCUS NEAR keys will have no
effect on the dome.
6.4.5
Patrol
In the Main menu press the PATROL key to enter the menu for carrying out the movement controls
START SEQUENCE 1…4
Used to start the corresponding sequence.
START CRUISE
Used to start the “CRUISE” function.
The settings for the sequences and for “Cruise” are made using the dome OSM.
See the dome handbook.
6.4.6
Preset, Scan and Home
The PRESET, SCAN and HOME functions are described in sections (§ 4.4.1.1 - PRESET, page 46 e § 4.4.2 -
SCAN MENU, page 48).
Refer to § 9.2.1 – Dome, page 165 to check the specific limits of the dome.
The HOME function loads a particular Preset position that can be set in the dome OSM.
See the dome handbook.
6.4.7
Function keys
In the Main menu press the PROG key (see § 4.4.1 - PROG MENU, page 46) and then the
key to enter the
menu for carrying out the specific controls.
F1
Associated function: “Line lock incr”.
F2
Associated function: “Line lock decr”.
See the dome handbook.
