6.11.7
Special codes
Some parameters can be configured by inserting a special code.
Go to the page for inserting special codes (see § 6.1.5 - Layout of the configuration menus, page 76) and
insert the numeric values using the keypad.
Code
Function
0
PAN position 0.
SPEED CURVES
11
First speed curve (speed values: 1, 5, 10, 20, 30, 45, 63).
12
Second speed curve (speed values: 1, 10, 20, 30, 40, 50, 63).
13
Third speed curve (speed values: 10, 15, 20, 25, 30, 45, 63).
14
Fourth speed curve (default) (speed values: 29, 37, 45, 50, 55, 59, 63).
15
Fifth speed curve (speed values: 10, 15, 20, 30, 40, 50, 63).
16
Sixth speed curve (can be customised by the user, but has default values:
10, 15, 20, 30, 55, 100, 255).(*)
8ZZZ
ZZZ = 000 ÷ 255: speed value. (*)
900X
X = 1 ÷ 7: Speed No. associated with speed value ZZZ.
910X
X = 1 ÷ 7: dome movement test at fixed speed No. X.
Move the joystick to break off the test.
Example
“8007”: speed value equal to 7 (ZZZ = 007)
“9001”; the speed value of 7 is assigned to speed No. 1 (X = 1)
...insertion of speed values for speed Nos. 2, 3, 4, 5 and 6...
“8138”: speed value equal to 138 (ZZZ = 138)
“9007”; the speed value of 138 is assigned to speed No. 7 (X = 7)
Now we test speed No. 7:
“9107”: the dome moves at the fixed speed of 138 (X = 7)
“16”: from now on every time the joystick is moved the dome will move at the speed that
the user has assigned to the sixth curve (X = 16)
(*) The Pelco D protocol accepts a maximum speed value of 63. Correct operation cannot be guaranteed for
higher speed settings.
ZONE
20
Start the SCAN of the zone.
21
End the SCAN of the zone.
10X
X = 1 ÷ 8: Set the start of the zone.
20X
X = 1 ÷ 8: Set the end of the zone.
AUTOFOCUS
40
AUTOFOCUS On.
41
AUTOFOCUS Off.
42
Automatic AUTOFOCUS On.
AUTOIRIS
50
AUTOIRIS On.
