EXAMPLE
If you want to store Preset positions 11, 73, 88 and 128 and assign the following parameters and Patrols:
Position 11: default parameters and Patrol
Position 73: dwell time 5 s, approach speed 6, assigned to Patrol No. 2
Position 88: as position 73
Position 128: dwell time 16 s, approach speed 4, assigned to all Patrols
Position 11
When the Preset keypad is displayed, insert the number 11 and confirm with the “ enter ” key.
Position 73
Press the “ptrl
SETUP
” key on the Preset keypad.
On the new page press the key and insert the value 5 using the keypad. Confirm and exit.
Press the key, insert the number 6, confirm and exit.
Use the cursor to select Patrol No. 1 and press “ ent ” to remove the position; then select Patrol No. 2
and press “ ent ” to select it. Press the “ esc ” key to return to the Preset keypad.
Insert the number 73 and press “ enter ” to confirm.
Position 88
Insert the number 88 using the Preset keypad and press “ enter ” to confirm.
Position 128
Press the “ptrl
SETUP
” key on the Preset keypad.
On the new page press the key and insert the number 16 using the keypad. Confirm and exit.
Press the key, insert the number 4, confirm and exit.
Use the cursor to select Patrol No. 1 and press “ ent ” to add the position; repeat for Patrol Nos. 4 and 5.
Press the “ esc ” key to return to the Preset keypad.
Insert the number 128 and press “ enter ” to confirm.
Press the “ esc ” key to exit from the Preset keypad.
6.9.7 Titling cameras, preset positions, zones
In the main menu press the PROG/DOME/”Setup ABC” keys consecutively to display the “TITLING” page,
where it is possible to choose the type of titling.
Titling is used to display on the monitor an alphanumeric string comprising a maximum of 14 characters. It is
possible to assign a title to a given camera, to a Preset position or to a zone, by selecting the desired type of
titling and pressing the “
ent ” key.
