4.2.6.5.2
Forcing the touch screen to the default values
This procedure is used to force the touch screen to the default values to allow its fine calibration.
Proceed as follows:
disconnect all the devices connected to the keyboard;
remove the power supply cable;
position DIP switch 1 to the ON position (see § 2.5 - DIP switch page 11);
power the keyboard and wait for the following screen to show
Operate the joystick as shown below:
After the message “
… reset touch
” has appeared return DIP1 to the OFF
position.
It is possible to directly select the menu for fine calibration of the touch screen by moving the joystick as
shown in the illustration or by restarting the keyboard, setting DIP1 to the OFF position.
Proceed as instructed in the particular section(see § 4.2.6.5 - Calibrating the touch screen, page 40).
