Table 4
INDIRECT connection
DVR model Type Protocol Baud rate Address Ext. DVR/MUX
ENEO
DLR-204/109/116
Mtx VIDEOTEC (1) MACRO 1200-38400 (2) ENEO DLR-204/109/116
SAMSUNG
SHR4160P
Mtx VIDEOTEC (1) MACRO 1200-38400 (2) SAMSUNG DVR
SANYO
DSR-3009P
DSR-3016P
DSR-3716P
Mtx VIDEOTEC (1) MACRO 1200-38400 (2) SANYO DVR
SONY
HSR-X216P
Mtx VIDEOTEC (1) MACRO 1200-38400 (2) SONY DVR
MUX model Type Protocol Baud rate Address Ext. DVR/MUX
ADEMCO
AXMD16E / AXCD16EX
Mtx VIDEOTEC (1) MACRO 1200-38400 (2) ADEMCO MUX
ENEO
VCMT-8009/8016
VBMT-8009/8016
Mtx VIDEOTEC (1) MACRO 1200-38400 (2)
ENEO MUX VCM
ENEO MUX VBM
SANYO
MPX-CD93P
MPX-CD163P
Mtx VIDEOTEC (1) MACRO 1200-38400 (2) SANYO MUX
SONY
YS-DX516P
Mtx VIDEOTEC (1) MACRO 1200-38400 (2) SONY MUX
VIDEOTEC
SP16C
Mtx VIDEOTEC (1) MACRO 1200-38400 (2)
SP16C or
SP16C-A (addressable)
(1) Verify which matrix models are able to manage the protocol used by the DVR/MUX.
(2) The presence of more than one keyboard connected to the matrix implies it is necessary to define different
identification addresses for each one.
5.4.1 Common operations
This section describes the various configuration operations that are common to all DVR/MUX models. Special
cases are covered in the specific sections for each model.
