10.2.2.4 Group 2 – Video switching control
We associate the various parameter values with each of the two buttons, following the sequence shown in the
illustration:
1. Select “Local DVR/MUX”
2. Select “Select DVR/MUX” and insert the address of the device (1 in this case);
3. Select “Select camera” and insert the camera number (1 in this case).
Selecting a video
switching control
When the first key is pressed the command will be sent to load camera No. 1 of the device with address No. 1.
When the second key is pressed, on the other hand, this will correspond to sending the command to load
camera No. 2 of the device with address No. 1.
These are the controls that will be transmitted from the keyboard when the keys are pressed:
BUTTON CONTROL
1 [VA0KB1VidS1,1V]
2 [VA0KB1VidS1,2W]
Page 172 of 176 MNVADCT03_0716
1
2
3
