5.3 Controllable video matrixes
The table describes how to configure the keyboard for all models of matrixes that can be controlled. The
columns refer to the fields present in the COMMUNICATIONS/VIDEO submenu (see § 4.2.3.1 - Video, page
22).
The following paragraphs give a detailed description of the specific cases.
Matrix model Type Protocol Baud rate Address Ext.
DVR/MUX
ENEO EKR-8/4 8/4 ENEO EKR MACRO 38400 1..4 (2) ------------ (4)
ENEO EKR-16/4 16/4 ENEO EKR MACRO 38400 1..4 (2) ------------ (4)
ENEO EKR-32/8 32/8 ENEO EKR MACRO 38400 1..8 (3) ------------ (4)
ENEO VKR-16/4 16/4 ENEO VKR ENEO 9600 1..4 (2) ------------
ENEO VKR 32/8 32/8 ENEO VKR ENEO 9600 1..4 (2) ------------
VIDEOTEC SM42A 4/2 VIDEOTEC MACRO 38400 1..4 (2) ------------ (4)
VIDEOTEC SM82A 8/2 VIDEOTEC MACRO 38400 1..4 (2) ------------ (4)
VIDEOTEC SM84A 8/4 VIDEOTEC MACRO 38400 1..4 (2) ------------ (4)
VIDEOTEC SM164A 16/4 VIDEOTEC MACRO 38400 1..4 (2) ------------ (4)
VIDEOTEC SM328A
(Single matrix)
32/8 VIDEOTEC MACRO 38400 1..8 (3) ------------ (4)
VIDEOTEC SM328A
(Parallel or
master/slave connection)
128/16 VIDEOTEC MACRO 38400 1..8 (3) ------------
VIDEOTEC SW328 32/8 VIDEOTEC VIDEOTEC 9600 1..8 (3) ------------
VIDEOTEC SW164OSM 16/4 VIDEOTEC VIDEOTEC 1200-9600 (1) ------------
Linxs LXRPS42A 4/2 VIDEOTEC LINXS 1200-9600 (1) ------------
Linxs LXRPS82A 8/2 VIDEOTEC LINXS 1200-9600 (1) ------------
Linxs LXRPS84A 8/4 VIDEOTEC LINXS 1200-9600 (1) ------------
Linxs LXRPS164A 16/4 VIDEOTEC LINXS 1200-9600 (1) ------------
(1) Even when there is more than one keyboard the identification number of each one is irrelevant.
(2) The presence of more than one keyboard connected to the matrix means you must define different
identification numbers (from 1 to 4) for each keyboard.
(3) The presence of more than one keyboard connected to the matrix means you must define different
identification numbers (from 1 to 8) for each keyboard.
(4) If used, select the type (see § 4.2.3.1.3 - Ext DVR/MUX, page 24) and set the accepted values (see §
4.2.4.4 - External DVR/MUX, page 34).
