Model GFC7000E Instruction Manual Operating Instructions
04584 Rev A1 80
To cause the analyzer to measure and record a value for PRES, press.
SAMPLE RANGE = 500.000 PPM CO2 =X.XXX
< TST TST > CAL SETUP
SAMPLE ENTER SETUP PASS : 818
8 1 8 ENTR EXIT
SETUP X.X PRIMARY SETUP MENU
CFG DAS RNGE PASS CLK MORE EXIT
SETUP X.X SECONDARY SETUP MENU
COMM VARS DIAG ALRM EXIT
Adjust these values until
the displayed flow rate
equals the flow rate being
measured by the
independent flow meter.
DIAG SIGNAL I / O
NEXT ENTR EXIT Exit at
any time
to return
to main
the
SETUP
menu
DIAG SIGNAL I / O
NEXT ENTR EXIT
Repeat Pressing NEXT until . . .
DIAG FCAL ACTUAL PRESS : 27.20 IN-HG-A
2 7 .2 0 ENTR EXIT
ENTR accepts the
new value and
returns to the
previous menu
EXIT ignores the
new value and
returns to the
previous menu
6.9.8. Flow Calibration
The flow calibration allows the user to adjust the values of the sample flow rates as they are
displayed on the front panel and reported through COM ports to match the actual flow rate
measured at the sample inlet. This does not change the hardware measurement of the flow
sensors, only the software calculated values.
To carry out this adjustment, connect an external, sufficiently accurate flow meter to the sample
inlet (see Chapter 11 for more details). Once the flow meter is attached and is measuring actual
gas flow, press:
SAMPLE RANGE = 500.000 PPM CO2 =X.XXX
< TST TST > CAL SETUP
SAMPLE ENTER SETUP PASS : 818
8 1 8 ENTR EXIT
SETUP X.X PRIMARY SETUP MENU
CFG DAS RNGE PASS CLK MORE EXIT
SETUP X.X SECONDARY SETUP MENU
COMM VARS DIAG ALRM EXIT
Exit at
any time
to return
to main
the
SETUP
menu
DIAG SIGNAL I / O
NEXT ENTR EXIT
Repeat Pressing NEXT until . . .
DIAG FLOW CALIBRATION
PREV NEXT ENTR EXIT
DIAG FCAL ACTUAL FLOW: 607 CC / M
0 6 0 7 ENTR EXIT
ENTR accepts the
new value and
returns to the
previous menu
EXIT ignores the
new value and
returns to the
previous menu
Adjust these values until
the displayed flow rate
equals the flow rate being
measured by the
independent flow meter.
