6.12.2.4. Editing iDAS Parameters

Data channels can be edited individually from the front panel without affecting other data
channels. However, when editing a data channel, such as during adding, deleting or editing

parameters, all data for that particular channel will be lost, because the iDAS can store only data
of one format (number of parameter columns etc.) for any given channel. In addition, an iDAS

configuration can only be uploaded remotely as an entire set of channels. Hence, remote update
of the iDAS will always delete all current channels and stored data.

To modify, add or delete a parameter, follow the instruction shown in section 6.12.2.2 then press:

Edit Data Parameter Menu

Edit Data Channel Menu

SETUP X.X

0) CONC: ATIMER, 1, 900

PREV NEXT INS DEL

EDIT

PRNT

EXIT

Exits to the main

Data Acquisition

SETUP X.X

NAME:CONC

SET>

EDIT

EXIT

SETUP X.X

PARAMETERS:1

EDIT

EXIT

SETUP X.X

0) PARAM=CONC1, MODE=AVG

PREV NEXT

INS DEL EDIT EXIT

Press SET> key until…

SETUP X.X

EDIT PARAMS (DELETE DATA)

YES NO

NO returns to

the previous

menu and

retains all data.

Moves the

display between

existing

Parameters

Inserts a new Parameter

before the currently

displayed Parameter

Deletes the Parameter

currently displayed.

Use to configure

the functions for

this Parameter.

Exits to the main

Data Acquisition

YES will delete

all data in that

entire channel.

From the DATA ACQUISITION menu

(see Section 6.12.2.2)
