Model GFC7000E Instruction Manual APPENDIX A-1: MGFC7000E Software Menu Trees, Revision E.0
045840110 Rev B.3 224
LOW HIGH
ZERO SPAN CONC
SAMPLE
SETUP
COMM DIAG VARS
(Secondary Setup Menu)
CFG DAS RANG PASS CLK MORE
( Primary Setup Menu)
Only appear if
reporting range
is set for
AUTO range
mode.
LOW HIGH
ZERO
LOW HIGH
SPAN CONC
MSG 1,2 CLR 1,3 CAL CALZ CALS TEST 1
1 Only appears when warning messages are activated
(see Section 6.2.2)
2 Press this key to cycle through list of active warning
messages.
3 Press this key to clear/erase the warning message
currently displayed
RANGE
RANGE1 *
RANGE2 *
STABIL
CO2 MEAS
CO2 REF
MR RATIO
PRES
SAMP FL
SAMP TEMP
BENCH TEMP
WHEEL TEMP
BOX TEMP
PHT DRIVE
SLOPE
OFFSET
TEST
TIME
TEST FUNCTIONS
Viewable by user while
instrument is in SAMPLE Mode
(see Section 6.2.1)
* Only appears instrument is set for
DUAL or AUTO reporting range
modes
ENTER SETUP PASS: 818
Figure A-2: Sample Display Menu - Units with Z/S Valve or IZS Option installed
