6.12.2.1. Viewing iDAS Data and Settings
iDAS data and settings can be viewed on the front panel through the following keystroke
sequence.
SAMPLE ENTER SETUP PASS : 818
8 1 8 ENTR EXIT
SAMPLE* RANGE = 500.000 PPM CO2 =X.XXX
< TST TST > CAL SETUP
SETUP X.X CONC : DATA AVAILABLE
NEXT VIEW EXIT
SETUP X.X PNUMTC : DATA AVAILABLE
PREV NEXT VIEW EXIT
SETUP X.X CALDAT : DATA AVAILABLE
PREV NEXT VIEW EXIT
SETUP X.X 00:00:00 NXSLP1=0.000
PV10 PREV PRM> EXIT
SETUP X.X 00:00:00 NXCNC1=0.0 PPM
PV10 PREV NEXT NX10 PRM> EXIT
SETUP X.X 00:00:00 SMPFLW=000.0 cc / m
PRM> EXIT
SETUP X.X DATA ACQUISITION
VIEW EDIT EXIT
SETUP X.X PRIMARY SETUP MENU
CFG DAS RNGE PASS CLK MORE EXIT
VIEW KEYPAD FUNCTIONS
KEY FUNCTION
Moves to the next Parameter
PRM> Moves to the previous
Parameter
NX10 Moves the view forward 10
data points/channels
NEXT Moves to the next data
point/channel
PREV Moves to the previous data
point/channel
PV10 Moves the view back 10 data
points/channels
Keys only appear as needed
SETUP X.X STBZRO : DATA AVAILABLE
PREV NEXT VIEW EXIT
SETUP X.X 00:00:00 STABIL=0.000
PV10 PREV PRM> EXIT
SETUP X.X STBSPN : DATA AVAILABLE
PREV NEXT VIEW EXIT
SETUP X.X 00:00:00 DETMES=0.000
PV10 PREV PRM> EXIT
SETUP X.X TEMP : DATA AVAILABLE
PREV NEXT VIEW EXIT
SETUP X.X 00:00:00 BOXTMP=0.000
PV10 PREV PRM> EXIT
