Model GFC7000E Instruction Manual Operating Instructions
04584 Rev A1 48
To view the TEST Functions press the following Key sequence:
RANGE
RANGE1 1
RANGE2 1
STABIL
CO2 MEAS
CO2 REF
MR RATIO
PRES
SAMP FL
SAMP TEMP
BENCH TEMP
WHEEL TEMP
BOX TEMP
PHT DRIVE
SLOPE
OFFSET
TEST
TIME
SAMPLE RANGE = 500.000 PPM CO2 = XXX.X
< TST TST > CAL SETUP
1
Only appears instrument is set
for DUAL or AUTO reporting
range modes
Refer to
Table 6-2
for
definitions
of these
test
functions.
Toggle keys to
scroll through list of functions
Figure 6-2 Viewing MGFC7000E TEST Functions
NOTE
A value of “XXXX” displayed for any of the TEST functions indicates an out-of-range
reading or the analyzer’s inability to calculate it.
All pressure measurements are represented in terms of absolute pressure. Absolute,
atmospheric pressure is 29.92 in-Hg-A at sea level. It decreases about 1 in-Hg per 300
m gain in altitude. A variety of factors such as air conditioning and passing storms can
cause changes in the absolute atmospheric pressure.
6.2.2. Warning Messages
The most common instrument failures will be reported as a warning on the analyzer’s front panel
and through the COM ports. Section 11.1.1 explains how to use these messages to troubleshoot
problems. Section 3.2.3 shows how to view and clear warning messages.
Table 6-3 lists all warning messages for the current version of software.
