6.4. SETUP Mode
The SETUP mode contains a variety of choices that are used to configure the analyzer’s hardware
and software features, perform diagnostic procedures, gather information on the instruments
performance and configure or access data from the internal data acquisition system (iDAS). For a
visual representation of the software menu trees, refer to Appendix A-1.
The areas access under the Setup mode are:
Table 6-4: Primary Setup Mode Features and Functions
MODE OR FEATURE
KEYPAD
LABEL
DESCRIPTION
MANUAL
SECTION
Analyzer Configuration CFG
Lists key hardware and software configuration
information
6.5
Auto Cal Feature ACAL
Used to set up an operate the AutoCal feature.
Only appears if the analyzer has one of the internal
valve options installed
7.6
Internal Data Acquisition
(iDAS)
DAS Used to set up the iDAS system and view recorded data 6.12
Analog Output Reporting
Range Configuration
RNGE
Used to configure the output signals generated by the
instruments Analog outputs.
6.7
Calibration Password
Security
PASS Turns the calibration password feature ON/OFF 6.3.1
Internal Clock
Configuration
CLK Used to Set or adjust the instrument’s internal clock 6.6
Advanced SETUP features MORE
This button accesses the instruments secondary setup
menu See
Table 6-5
Table 6-5: Secondary Setup Mode Features and Functions
MODE OR FEATURE
KEYPAD
LABEL
DESCRIPTION
MANUAL
SECTION
External Communication
Channel Configuration
COMM
Used to set up and operate the analyzer’s various
external I/O channels including RS-232; RS 485,
modem communication and/or Ethernet access.
6.10 &
6.13
System Status Variables VARS
Used to view various variables related to the
instruments current operational status
6.8
System Diagnostic
Features
DIAG
Used to access a variety of functions that are used to
configure, test or diagnose problems with a variety of
the analyzer’s basic systems 6.9
CO
2
Concentration Alarms ALRM
Used to activate the analyzer’s two gas concentration
status alarms and set the alarm limits
6.11
NOTE
Any changes made to a variable during one of the following procedures is not
acknowledged by the instrument until the ENTR Key is pressed
