6.10.9.3. Manually Configuring the Network IP Addresses
There are several circumstances when you may need to manually configure the interface settings
of the analyzer’s Ethernet card. The INET sub-menu may also be used to edit the Ethernet card’s
configuration properties
• Your LAN is not running a DHCP software package,
• The DHCP software is unable to initialize the analyzer’s interface;
• You wish to program the interface with a specific set of IP addresses that may not be the
ones automatically chosen by DHCP.
Editing the Ethernet Interface properties is a two step process.
STEP 1: Turn DHCP OFF: While DHCP is turned ON, the ability to manually set INSTRUMENT IP,
GATEWAY IP and SUBNET MASK is disabled
ENTR accept
new settings
EXIT ignores
new settings
SETUP X.X
PRIMARY SETUP MENU
CFG DAS RNGE PASS CLK MORE EXIT
SAMPLE ENTER SETUP PASS : 818
8 1 8 ENTR EXIT
SAMPLE* RANGE = 500.000 PPM CO2 =X.XXX
< TST TST > CAL SETUP
SETUP X.X COMMUNICATIONS MENU
ID INET COM1 EXIT
SETUP X.X
SECONDARY SETUP MENU
COMM VARS DIAG ALRM EXIT
SETUP X.X DHCP: ON
ON ENTR EXIT
SETUP X.X DHCP: ON
EDIT EXIT
SETUP X.X DHCP: ON
OFF ENTR EXIT
Continue with editing of Ethernet interface
properties (see Step 2, below).
