8. VENTILATION CLEARANCE: Whether the analyzer is set up on a bench or installed into an
instrument rack, be sure to leave sufficient ventilation clearance.
AREA MINIMUM REQUIRED CLEARANCE
Back of the instrument 4 in.
Sides of the instrument 1 in.
Above and below the instrument 1 in.
• Various rack mount kits are available for this analyzer. See Section 5.1 of this manual
for more information.
3.1.1. Electrical Connections
CAUTION
Check the voltage and frequency label on the rear panel of the
instrument (See Figure 3-2) for compatibility with the local
power before plugging the MGFC7000E into line power.
Do not plug in the power cord if the voltage or
frequency is incorrect.
CAUTION
Power connection must have functioning ground connection.
Do not defeat the ground wire on power plug.
CAUTION
Turn off analyzer power before disconnecting or
connecting electrical subassemblies.
Do not operate with cover off.
