Model GFC7000E Instruction Manual Operating Instructions
04584 Rev A1 110
Edit Data Channel Menu
SETUP X.X 0) CONC: ATIMER, 1 2, 900
PREV NEXT INS DEL
EDIT PRNT EXIT
Exits to the main
Data Acquisition
menu
SETUP X.X NAME:CONC
SET> EDIT PRINT EXIT
SETUP X.X NUMBER OF RECORDS:000
EDIT PRINT EXIT
SETUP X.X REPORT PERIODD:DAYS:0
0 0 0 0 0 ENTR EXIT
ENTR accepts the new
setting and returns to the
previous menu.
EXIT ignores the new setting
and returns to the previous
menu.
Toggle keys to set
number of records
(1-99999)
SETUP X.X EDIT RECOPRDS (DELET DATA)
YES NO
NO returns to the
previous menu. YES will delete all data
in this channel.
Press SET> key until…
From the DATA ACQUISITION menu
(see Section 6.12.2.2)
6.12.2.7. RS-232 Report Function
The MGFC7000E iDAS can automatically report data to the communications ports, where they can
be captured with a terminal emulation program or simply viewed by the user.
