3. GETTING STARTED
3.1. Unpacking and Initial Set Up
CAUTION
To avoid personal injury, always use two persons to lift and carry the
Model GFC7000E.
1. Verify that there is no apparent external shipping damage. If damage has occurred, please
advise the shipper first, then Teledyne Analytical Instruments.
2. Included with your analyzer is a printed record of the final performance characterization
performed on your instrument at the factory. This record, titled Final Test and Validation Data
Sheet (part number 04307) is an important quality assurance and calibration record for this
instrument. It should be placed in the quality records file for this instrument.
3. Carefully remove the top cover of the analyzer and check for internal shipping damage.
• Remove the set screw located in the top, center of the rear panel.
• Remove the four screws fastening the top cover to the unit (two per side).
• Lift the cover straight up. Do not slide backwards.
NOTE
Some versions of the GFC7000E CO
2
Analyzer may have a spring loaded fastener at the
top center of the rear panel and as many as eight screws (four per side) fastening the
top cover to the chassis.
NOTE
Static sensitive parts are present on PCA (Printed Circuit Assemblies). Before touching
PCAs, touch a bare metal part of the chassis to discharge any electrostatic potentials or
connect a grounding strap to your wrist.
CAUTION
Never disconnect PCAs, wiring harnesses or electronic subassemblies
while under power.
4. Inspect the interior of the instrument to make sure all circuit boards and other components
are in good shape and properly seated.
