Model GFC7000E Instruction Manual Getting Started
04584 Rev A1 25
To View and Clear the various warning messages press:
SAMPLE HVPS WARNING CO2 = 0.00
TEST CAL MSG CLR SETUP
Make sure warning messages are
not due to real problems.
Press CLR to clear the current
message.
If more than one warning is active, the
next message will take its place
Once the last warning has been
cleared, the analyzer returns to
SAMPLE mode
SAMPLE RANGE=500.000 PPM CO2 = 0.00
< TST TST > CAL
MSG CLR SETUP
SAMPLE HVPS WARNING CO2 = 0.00
TEST CAL
MSG CLR SETUP
TEST deactivates warning
messages
MSG activates warning
messages.
> keys replaced with
TEST key
NOTE:
If the warning message persists
after several attempts to clear it,
the message may indicate a
real problem and not an artifact
of the warm-up period
3.2.4. Functional Check
1. After the analyzer’s components has warmed up for at least 30 minutes, verify that the
software properly supports any hardware options that were installed.
2. Check to make sure that the analyzer is functioning within allowable operating parameters.
Appendix C includes a list of test functions viewable from the analyzer’s front panel as well as
their expected values. These functions are also useful tools for diagnosing performance
problems with your analyzer (Section 11.1.2). The enclosed Final Test and Validation Data
sheet (part number 04307) lists these values before the instrument left the factory.
To view the current values of these parameters press the following key sequence on the
analyzer’s front panel. Remember until the unit has completed its warm up these parameters
may not have stabilized.
RANGE
RANGE1 1
RANGE2 1
STABIL
CO2 MEAS
CO2 REF
MR RATIO
PRES
SAMP FL
SAMP TEMP
BENCH TEMP
WHEEL TEMP
BOX TEMP
PHT DRIVE
SLOPE
OFFSET
TEST
TIME
SAMPLE RANGE = 500.000 PPM CO2 = XXX.X
< TST TST > CAL SETUP
1
Only appears instrument is set
for DUAL or AUTO reporting
range modes
Refer to
Section
6.X.X for
definitions
of these
test
functions.
Toggle keys to
scroll through list of functions
