Model GFC7000E Instruction Manual Calibration Procedures
04584 Rev A1 141
To program the Sequence:
Toggle keys
to set
number of
days
between
procedures
(1-367)
Toggle keys
to set
delay time for
each iteration
of the
sequence:
HH:MM
(0 – 24:00)
SETUP X.X DELTA DAYS: 1
EDIT EXIT
SETUP X.X DELTA DAYS: 1
0 0 2 ENTR EXIT
SETUP X.X DELTA DAYS:2
SET> EDIT EXIT
SETUP X.X DELTA TIME00:00
EDIT EXIT
SETUP X.X DELTA TIME: 00:00
0 0 :3 0 ENTR EXIT
SETUP X.X DELTA TIEM:00:30
SET> EDIT EXIT
SETUP X.X STARTING TIM E:14:15
SET> EDIT EXIT
EXIT returns
to the SETUP
Menu
SETUP X.X DURATION:15.0 M INUTES
EDIT EXIT
SETUP X.X DURATION 15.0MINUTES
3 0 .0 ENTR EXIT
SETUP X.X DURATION:30.0 M INUTES
SET> EDIT EXIT
Toggle keys
to set
duration for
each
iteration of
the
sequence:
Set in
Decimal
minutes
from
0.1 – 60.0
SETUP X.X CALIBRATE: OFF
EDIT EXIT
SETUP X.X CALIBRATE: OFF
ON ENTR EXIT
SETUP X.X CALIBRATE: ON
EDIT
EXIT
Toggle key
between
Off and
ON
SETUP X.X SEQ 2) ZERO–SPAN, 2:00:30
PREV NEXT
MODE SET EXIT
Sequence Delta Time
MODE Delta Days
SAMPLE ENTER SETUP PASS : 818
8 1 8 ENTR EXIT
SETUP X.X PRIMARY SETUP MENU
CFG
ACAL DAS RNGE PASS CLK MORE EXIT
SETUP X.X SEQ 1) DISABLED
NEXT MODE EXIT
SETUP X.X SEQ 2) DISABLED
PREV NEXT
M ODE EXIT
SETUP X.X M ODE: DISABLED
NEXT ENTR EXIT
SETUP X.X MODE: ZERO
PREV
NEXT ENTR EXIT
SETUP X.X M ODE: ZERO–SPAN
PREV
NEXT ENTR EXIT
SETUP X.X SEQ 2) ZERO–SPAN, 1:00:00
PREV NEXT
MODE SET EXIT
SETUP X.X TIM ER ENABLE: ON
SET> EDIT EXIT
SETUP X.X STARTING DAT E: 01–JAN–02
EDIT EXIT
SETUP X.X STARTING DAT E: 01–JAN–02
0 4 SEP 0 3 ENTR EXIT
Toggle keys
to set
day, month &
year:
Form at :
DD-MON-Y Y
SETUP X.X STARTING DATE: 04–SEP–03
SET> EDIT EXIT
Default
value is
ON
SETUP X.X STARTING DATE: 04–SEP–03
SET> EDIT EXIT
SETUP X.X STARTING TIM E:00:00
EDIT EXIT
SETUP X.X STARTING TIME:00:00
1 4 : 1 5 ENTR EXIT/
Toggle keys to
set time:
Format : HH:MM
This is a 24 hr
clock .
PM hours are
13 – 24.
Example
2:15 PM = 14:15
SAMPLE* RANGE = 500.000 PPM CO2 =X.XXX
< TST TST > CAL CALZ CALS
SETUP
