Model GFC7000E Instruction Manual Optional Hardware and Software
04584 Rev A1 43
5.6.2. Manual on CD (Part number 045840200)
This operators manual is also available on CD. The electronic document is stored in Adobe
Systems Inc. Portable Document Format (PDF) and is viewable with Adobe Acrobat Reader ®
software, downloadable for free at http://www.adobe.com/
The CD version of the manual has many advantages:
• Fully searchable text.
• Hypertext links for figures, tables, table of contents and embedded references for quick
access of individual manual portions.
• A list of thumbnails, chapters and sections displayed at the left of the text.
• Internet links embedded in the manual will take you to the corresponding web site
(requires an internet connection).
5.7. Extended Warranty (Options 92 & 93)
Two options are available for extending Teledyne Instruments’ standard warranty (Section 2.3).
Both options have to be specified upon ordering the analyzer.
Option Number Description
OPT 92 Extends warranty to cover a two (2) year period from the date of
purchase.
OPT 93 Extends warranty to cover a five (5) year period from the date of
purchase.
5.8. Dilution Ratio Option
The Dilution Ration Option is a software option that is designed for applications where the Sample
gas is diluted before being analyzed by the Model GFC7000E. Typically this occurs in Continuous
Emission Monitoring (CEM) applications where the quality of gas in a smoke stack is being tested
and the sampling method used to remove the gas from the stack dilutes the gas.
Once the degree of dilution is known, this feature allows the user to add an appropriate scaling
factor to the analyzer’s CO
2
concentration calculation so that the Measurement Range and
concentration values displayed on the instrument’s Front Panel Display and reported via the
Analog and Serial Outputs reflect the undiluted values.
Instructions for using the dilution ratio option can be found in Section 6.7.7..
5.9. Maintenance Mode Switch
API’s instruments can be equipped with an switch that places the instrument in maintenance
mode. When present, the switch accessed by opening the hinged front panel and is located on
the rearward facing side of the display/keyboard driver PCA; on the left side; near the particulate
filter.
