6.9.1. Accessing the Diagnostic Features
To access the DIAG functions press the following keys:
SETUP X.X PRIMARY SETUP MENU
CFG DAS RNGE PASS CLK MORE EXIT
SETUP X.X SECONDARY SETUP MENU
COMM VARS DIAG ALRM EXIT
DIAG SIGNAL I / O
NEXT ENTR EXIT
DIAG ANALOG OUTPUT
PREV NEXT ENTR EXIT
SAMPLE* RANGE = 500.00 PPM CO2 =X.XXX
< TST TST > CAL SETUP
SAMPLE ENTER SETUP PASS : 818
8 1 8 ENTR EXIT
From this point
forward, EXIT returns
to the
SECONDARY
SETUP MENU
EXIT returns
to the PRIMARY
SETUP MENU
DIAG FLOW CALIBRATION
PREV NEXT ENTR EXIT
DIAG ELECTRICAL TEST
PREV NEXT ENTR EXIT
DIAG ANALOG I / O CONFIGURATION
PREV NEXT ENTR EXIT
DIAG DARK CALIBRATION
PREV NEXT ENTR EXIT
DIAG PRESSURE CALIBRATION
PREV NEXT ENTR EXIT
EXIT returns
to the main
SAMPLE
display
DIAG TEST CHAN OUTPUT
PREV NEXT ENTR EXIT
6.9.2. Signal I/O
The signal I/O diagnostic mode allows to review and change the digital and analog input/output
functions of the analyzer. See Appendix A-4 for a complete list of the parameters available for
review under this menu.
NOTE
Any changes of signal I/O settings will remain in effect only until the signal I/O menu is
exited. Exceptions are the ozone generator override and the flow sensor calibration,
which remain as entered when exiting.
