Model GFC7000E Instruction Manual
APPENDIX A-2: Setup Variables For Serial I/O, Revision
E.0APPENDIX A-3: Warnings and Test Functions, Revision E.0
045840110 Rev B.3
233
SETUP VARIABLE
NUMERIC
UNITS
DEFAULT VALUE
VALUE RANGE
DESCRIPTION
ET_TARGET_CONC
PPM 40,
400
3, 8
1–10000
Target concentration during
electrical test.
ET_CONC_RANGE
Conc. 50,
5000
3, 8
0.1–50000 D/A
concentration
range
during electrical test.
STD_TEMP
ºK 321
1–500
Standard
temperature
for
temperature compensation.
STD_PRESS
"Hg 28.5,
28.7
8
, 28.8
12
,
28.1
4
1–50
Standard pressure for
pressure compensation.
BENCH_SET
ºC 48
Warnings: 43–53
0–100
Optical bench temperature
set point and warning limits.
WHEEL_SET
ºC 68
Warnings: 63–73
0–100
Wheel temperature set point
and warning limits.
ZERO_ENABLE
3, 5, 8
— ON,
OFF
8
OFF,
ON
ON enables auto-zero
calibration using scrubber;
OFF disables it.
ZERO_FREQ
3, 5, 8
Minutes 5,
20
5
0.1–1440 Auto-zero
calibration
frequency.
ZERO_DWELL
3, 5, 8
Seconds,
Minutes
5
7, 5
5
1–60, 1–30
5
Dwell time after closing or
opening zero scrubber valve.
ZERO_SAMPLES
3, 5, 8
Samples
15
1–1000
Number of zero samples to
average.
ZERO_FILT_SIZE
3, 5, 8
Samples 5
1–100
Auto-zero
offset
moving
average filter size.
ZERO_LIMIT
3, 5, 8
Ratio 1.2,
1.15
3, 8
0–5
Minimum auto-zero ratio
allowed; must be greater
than this value to be valid.
ZERO_CAL
3, 5, 8
Ratio
1.18
0.5–5
Calibrated auto-zero ratio.
CO_SPAN1
Conc. 40,
400
3, 8
1–10000,
1–20000
3, 8
Target CO concentration
during span calibration of
range 1.
CO_SLOPE1
—
1
0.001–999.999
CO slope for range 1.
CO_OFFSET1
—
0
-10–10
CO offset for range 1.
CO_SPAN2
Conc. 40,
400
3, 8
1–10000,
1–20000
3, 8
Target CO concentration
during span calibration of
range 2.
CO_SLOPE2
—
1
0.001–999.999
CO slope for range 2.
CO_OFFSET2
—
0
-10–10
CO offset for range 2.
RANGE_MODE
— SNGL
0
SNGL,
DUAL,
AUTO
Range control mode.
CONC_RANGE1
Conc. 50,
200
6
, 500
3, 8
0.1–50000
D/A concentration range 1.
CONC_RANGE2
1
Conc. 50,
200
6
, 500
3, 8
0.1–50000
D/A concentration range 2.
CONC_RANGE3
10
%
15
1–15
D/A concentration range 3
(CO
2
).
