PD17062
Fig. 6-5 Execution of the Above Example
Also, note the following when the general-purpose register is being used. No arithmetic/logical instructions
are provided for the general-purpose register and immediate data. That is, the execution of an arithmetic/
logical instruction that involves data memory allocated as the general-purpose register and immediate data
requires that the data memory be treated as data memory rather than the general-purpose register.
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
0
2
3
4
5
6
7
1
RP
BANK0
RP = 0000010B
LD
04H,
32H
System register
Column address
General-purpose register
Row address
