µ
PD17062
Symbol
Attribute
Value
Read/
Description
write
SIO0SF8
FLG
0.0A8H.3
R
SIO0 shift 8 clock flag
SIO0SF9
FLG
0.0A8H.2
R
SIO0 shift 9 clock flag
SBSTT
FLG
0.0A8H.1
R
Serial bus start test flag
SBBSY
FLG
0.0A8H.0
R
Serial bus busy flag
IPSIO0
FLG
0.0AFH.3
R/W
SIO0 interrupt permission flag
IPVSYN
FLG
0.0AFH.2
R/W
Vsync interrupt permission flag
IPBTM0
FLG
0.0AFH.1
R/W
Timer 0 interrupt permission flag
IPNC
FLG
0.0AFH.0
R/W
INTNC interrupt permission flag
CROMBNK
FLG
0.0B0H.0
R/W
CROM bank selection flag
IDCEN
FLG
0.0B1H.0
R/W
IDC enable flag
PLULSEN3
FLG
0.0B2H.3
R/W
PLL unlock time selection flag (dummy: 0)
PLULSEN2
FLG
0.0B2H.2
R/W
PLL unlock time selection flag (dummy: 0)
PLULSEN1
FLG
0.0B2H.1
R/W
PLL unlock time selection flag
PLULSEN0
FLG
0.0B2H.0
R/W
PLL unlock time selection flag
P1BBIO3
FLG
0.0B5H.3
R/W
P1B3 I/O selection flag
P1BBIO2
FLG
0.0B5H.2
R/W
P1B2 I/O selection flag
P1BBIO1
FLG
0.0B5H.1
R/W
P1B1 I/O selection flag
P1BBIO0
FLG
0.0B5H.0
R/W
P1B0 I/O selection flag
P0BBIO3
FLG
0.0B6H.3
R/W
P0B3 I/O selection flag
P0BBIO2
FLG
0.0B6H.2
R/W
P0B2 I/O selection flag
P0BBIO1
FLG
0.0B6H.1
R/W
P0B1 I/O selection flag
P0BBIO0
FLG
0.0B6H.0
R/W
P0B0 I/O selection flag
P0ABIO3
FLG
0.0B7H.3
R/W
P0A3 I/O selection flag
P0ABIO2
FLG
0.0B7H.2
R/W
P0A2 I/O selection flag
P0ABIO1
FLG
0.0B7H.1
R/W
P0A1 I/O selection flag
P0ABIO0
FLG
0.0B7H.0
R/W
P0A0 I/O selection flag
SIO0IMD3
FLG
0.0B8H.3
R/W
SIO0 interrupt mode selection flag (dummy: 0)
SIO0IMD2
FLG
0.0B8H.2
R/W
SIO0 interrupt mode selection flag (dummy: 0)
SIO0IMD1
FLG
0.0B8H.1
R/W
SIO0 interrupt mode selection flag
SIO0IMD0
FLG
0.0B8H.0
R/W
SIO0 interrupt mode selection flag
SIO0CK3
FLG
0.0B9H.3
R/W
SIO0 shift clock selection flag (dummy: 0)
SIO0CK2
FLG
0.0B9H.2
R/W
SIO0 shift clock selection flag (dummy: 0)
SIO0CK1
FLG
0.0B9H.1
R/W
Serial clock selection
SIO0CK0
FLG
0.0B9H.0
R/W
Serial clock selection
IRQSIO0
FLG
0.0BFH.3
R
SIO0 interrupt request flag
IRQVSYN
FLG
0.0BFH.2
R
Vsync interrupt request flag
IRQBTM0
FLG
0.0BFH.1
R
Timer 0 interrupt request flag
IRQNC
FLG
0.0BFH.0
R
INT
NC
interrupt request flag
