4 register files – NEC PD17062 User Manual
Page 284
284
µ
PD17062
Symbol
Attribute
Value
Read/
Description
write
IDCDMAEN
FLG
0.80H.1
R/W
DMA enable flag
SP
MEM
0.81H
R/W
Stack pointer
CE
FLG
0.87H.0
R
CE pin status flag
SIO0CH
FLG
0.88H.3
R/W
SIO0 channel selection flag
SB
FLG
0.88H.2
R/W
SIO0 mode selection flag
SIO0MS
FLG
0.88H.1
R/W
SIO0 clock mode selection flag
SIO0TX
FLG
0.88H.0
R/W
SIO0 TX/RX selection mode
BTM0ZX
FLG
0.89H.3
R/W
Timer 0 interrupt mode selection flag
BTM0CK2
FLG
0.89H.2
R/W
Timer 0 carry FF mode selection flag
BTM0CK1
FLG
0.89H.1
R/W
Timer 0 carry FF mode selection flag
BTM0CK0
FLG
0.89H.0
R/W
Timer 0 carry FF mode selection flag
INTVSYN
FLG
0.8FH.2
R
Vsync pin status flag
INTNC
FLG
0.8FH.0
R
INT
NC
pin status flag
HSCGT3
FLG
0.91H.3
R/W
Hsync counter mode selection flag (dummy: 0)
HSCGT2
FLG
0.91H.2
R/W
Hsync counter mode selection flag (dummy: 0)
HSCGT1
FLG
0.91H.1
R/W
Hsync counter mode selection flag
HSCGT0
FLG
0.91H.0
R/W
Hsync counter mode selection flag
HSCGOSTT
FLG
0.92H.3
R
Hsync counter gate open flag
PLLRFCK3
FLG
0.93H.3
R/W
PLL reference clock selection flag
PLLRFCK2
FLG
0.93H.2
R/W
PLL reference clock selection flag
PLLRFCK1
FLG
0.93H.1
R/W
PLL reference clock selection flag
PLLRFCK0
FLG
0.93H.0
R/W
PLL reference clock selection flag
INTNCMD3
FLG
0.95H.3
R/W
INT
NC
pin status flag (dummy)
INTNCMD2
FLG
0.95H.2
R/W
INT
NC
pin status flag
INTNCMD1
FLG
0.95H.1
R/W
INT
NC
pin status flag
INTNCMD0
FLG
0.95H.0
R/W
INT
NC
pin status flag
BTM0CY
FLG
0.97H.0
R
Timer 0 carry FF status flag
SBACK
FLG
0.98H.3
R/W
Serial bus acknowledge flag
SIO0NWT
FLG
0.98H.2
R/W
SIO0 no wait flag
SIO0WRQ1
FLG
0.98H.1
R/W
SIO0 wait request flag
SIO0WRQ0
FLG
0.98H.0
R/W
SIO0 wait request flag
IEGVSYN
FLG
0.9FH.2
R/W
Vsync interrupt edge selection flag
IEGNC
FLG
0.9FH.0
R/W
INTNC interrupt edge selection flag
ADCCH2
FLG
0.0A1H.3
R/W
A/D converter channel selection flag
ADCCH1
FLG
0.0A1H.2
R/W
A/D converter channel selection flag
ADCCH0
FLG
0.0A1H.1
R/W
A/D converter channel selection flag
ADCCMP
FLG
0.0A1H.0
R/W
A/D converter judge flag
PLLUL
FLG
0.0A2H.0
R
PLL unlock FF flag
P1CGIO
FLG
0.0A7H.0
R/W
Port 1C I/O selection flag
23.4 REGISTER FILES
