277
µ
PD17062
22. INSTRUCTION SETS
22.1 OUTLINE OF INSTRUCTION SETS
b 15
b
14
-b
11
0 1
BIN HEX
0 0 0 0 0 ADD r, m ADD m, #n4
0 0 0 1 1 SUB r, m SUB m, #n4
0 0 1 0 2 ADDC r, m ADDC m, #n4
0 0 1 1 3 SUBC r, m SUBC m, #n4
0 1 0 0 4 AND r, m AND m, #n4
0 1 0 1 5 XOR r, m XOR m, #n4
0 1 1 0 6 OR r, m OR m, #n4
INC AR
INC IX
MOVT DBF, @AR
BR @AR
CALL @AR
RET
RETSK
EI
DI
0 1 1 1 7 RETI
PUSH AR
POP AR
GET DBF, p
PUT p, DBF
PEEK WR, rf
POKE rf, WR
RORC r
STOP s
HALT h
NOP
1 0 0 0 8 LD r, m ST m, r
1 0 0 1 9 SKE m, #n4 SKGE m, #n4
1 0 1 0 A MOV @r, m MOV m, @r
1 0 1 1 B SKNE m, #n4 SKLT m, #n4
1 1 0 0 C BR addr (page 0) CALL addr (page 0)
1 1 0 1 D BR addr (page 1) MOV m, #n4
1 1 1 0 E SKT m, #n
1 1 1 1 F SKF m, #n
