µ
PD17062
The program shown below is an example of a program that meets the above condition. Do not creates
such a program.
Example
Process A
INITFLG NOT BTM0ZX, NOT BTM0CK2, NOT BTM0CK1, BTM0CK0
; Built-in macro
; Specifies the timer carry FF set pulse as 5 ms.
LOOP:
;
#
SKT1 BTM0CY ; Built-in macro
BR
BBB
AAA:
496 steps
BR
LOOP
BBB:
496 steps
BR
LOOP
Because the BTM0CY flag read instruction at
# in this program is executed at every 500 instructions, once
the BTM0CY flag happens to be set at the timing of the instruction at
#, a CE reset will not occur forever.
In addition, because the instruction execution time is 12
µ
s (1/83.33 kHz) during the operation of the IDC,
do not create a cyclic program that meets the following condition.
t
SET
×
83.33 = n (n is any integer)
x
where t
SET
: BTM0CY flag setting time interval
x
: BTM0CY flag read instruction cycle time x number of steps
