NEC PD17062 - Manual (Page 283)

283
µ
PD17062
23.3 PORT REGISTER
Symbol Attribute Value
Read/
Description
write
P0A3 FLG 0.70H.3 R/W Bit 3 of port 0A
P0A2 FLG 0.70H.2 R/W Bit 2 of port 0A
P0A1 FLG 0.70H.1 R/W Bit 1 of port 0A
P0A0 FLG 0.70H.0 R/W Bit 0 of port 0A
P0B3 FLG 0.71H.3 R/W Bit 3 of port 0B
P0B2 FLG 0.71H.2 R/W Bit 2 of port 0B
P0B1 FLG 0.71H.1 R/W Bit 1 of port 0B
P0B0 FLG 0.71H.0 R/W Bit 0 of port 0B
P0C3 FLG 0.72H.3 R/W Bit 3 of port 0C
P0C2 FLG 0.72H.2 R/W Bit 2 of port 0C
P0C1 FLG 0.72H.1 R/W Bit 1 of port 0C
P0C0 FLG 0.72H.0 R/W Bit 0 of port 0C
P0D3 FLG 0.73H.3 R Note Bit 3 of port 0D
P0D2 FLG 0.73H.2 R Note Bit 2 of port 0D
P0D1 FLG 0.73H.1 R Note Bit 1 of port 0D
P0D0 FLG 0.73H.0 R Note Bit 0 of port 0D
P1A3 FLG 1.70H.3 R/W Bit 3 of port 1A
P1A2 FLG 1.70H.2 R/W Bit 2 of port 1A
P1A1 FLG 1.70H.1 R/W Bit 1 of port 1A
P1A0 FLG 1.70H.0 R/W Bit 0 of port 1A
P1B3 FLG 1.71H.3 R/W Bit 3 of port 1B
P1B2 FLG 1.71H.2 R/W Bit 2 of port 1B
P1B1 FLG 1.71H.1 R/W Bit 1 of port 1B
P1B0 FLG 1.71H.0 R/W Bit 0 of port 1B
P1C3 FLG 1.72H.3 R/W Bit 3 of port 1C
P1C2 FLG 1.72H.2 R/W Bit 2 of port 1C
P1C1 FLG 1.72H.1 R/W Bit 1 of port 1C
Note These are read-only ports. However, even if an output instruction is written, the assembler (IE-17K)
does not generate an error message. Also, operation is not affected even if it is actually executed
on the device.
