PD17062
64 PIN PLASTIC QFP ( 14)
ITEM
MILLIMETERS
INCHES
F
G
K
N
J
1.0
1.6±0.2
0.10
0.8 (T.P.)
1.0
Q
0.039
0.039
0.063±0.008
0.004
0.031 (T.P.)
S64GC-80-3BE-1
A
C
NOTE
Each lead centerline is located within 0.13 mm (0.005 inch) of
its true position (T.P.) at maximum material condition.
D
17.2±0.2
0.677±0.008
0.125±0.075
0.005±0.003
A
17.2±0.2
0.677±0.008
I
0.13
0.005
P
2.7
0.106
S
R
3.0 MAX.
5
°
±5
°
0.119 MAX.
5
°
±5
°
C
14.0±0.2
0.551 +0.009
–0.008
B
14.0±0.2
0.551+0.009
–0.008
H
0.35±0.10
0.014 +0.004
–0.005
M
0.15
0.006 +0.004
–0.003
L
0.8±0.2
0.031+0.009
–0.008
+0.10
–0.05
48
49
64
1
16
32
17
33
M
B
D
F
G
H
J
I
P
N
L
K
M
detail of lead end
S
Q
R
