24. ELECTRICAL CHARACTERISTICS
ABSOLUTE MAXIMUM RATINGS (T
a
= 25
±
2
°
C)
Parameter
Symbol
Rated value
Unit
Supply voltage
V
DD
–0.3 to +6.0
V
Input voltage
V
I
–0.3 to V
DD
+ 0.3
V
Output voltage
V
O
–0.3 to V
DD
+ 0.3 (excluding P1A
3
to P1A
0
and PWM
3
to PMW
0
)
V
Output absorption current
I
O
10 (excluding P1A)
mA
Output withstand voltage
V
BDS
13 (P1A, PWM)
V
Operating temperature
T
opt1
–20 to +70
°
C
T
opt2
–40 to +85 (when IDC has stopped)
Storage temperature
V
stg
–55 to +125
°
C
RECOMMENDED OPERATION RANGE (T
a
= –40 to +85
°
C)
Parameter
Symbol
Conditions
Min.
Typ.
Max.
Unit
Supply voltage
V
DD1
T
a
= –20 to +70
°
C (when CPU, PLL, and IDC are operating)
4.5
5.0
5.5
V
V
DD2
When CPU and PLL are operating (IDC is not operating)
4.5
5.0
5.5
V
V
DD3
When only CPU is operating (PLL and IDC are not operating)
4.0
5.0
5.5
V
Data hold voltage
V
DDR
When crystal oscillation has stopped
3.0
5.5
V
Output withstand voltage
V
BDS
P1B
3
-P1B
1
0.0
12.5
V
Input amplitude
V
in1
VCO
0.7
V
DD
V
P-P
Supply voltage rise time
t
rise
V
DD
: 0
→
4.0 V
500
ms
