1. PINS
1.1 PIN FUNCTIONS
Pin No.
DIP QFP
(GC)
Symbol
Description
Output type
At power-on reset
P0C
3
|
P0C
0
P0D
3
/ADC
5
|
P0D
0
/ADC
2
PWM
3
|
PWM
0
V
DD
V
DD1
V
DD0
VCO
EO
GND
GND2
GND1
GND0
PSC
CE
X
OUT
X
IN
1
|
4
5
|
8
9
|
12
13
14
15
16
17
18
19
20
58
|
61
62
|
1
2
|
6
9
11
13
15
16
17
18
19
4-bit output port
Input of port 0D and A/D converter
• P0D
3
to P0D
0
4-bit input port containing a pull-down resis-
tor.
• ADC
5
to ADC
2
Input of a 4-bit A/D converter, which is a soft-
ware-based successive-approximation type. The
reference voltage is V
DD
.
Output of a 6-bit D/A converter. The output type
is PWM. Output is done at a frequency of 15.625
kHz. The pin can also be used as a one-bit output
port.
Supplies the power to the device. To enable all
functions, 5 V
±
10% is supplied. To operate only
the CPU, 4 V is required. In the clock-stop state,
the voltage can be reduced to 3.5 V.
When the supply voltage increases from 0 V to 4
V, a power-on reset occurs and the program is
started from address 0.
Apply an identical voltage to all pins.
Inputs the signal obtained by dividing the local
oscillation output by the specialized prescaler.
Outputs the PLL error signal. The signal is input
through the external LPF to the local oscillation
circuit.
Grounds the device. Connect all pins to ground.
Outputs the signal to switch the frequency divi-
sion ratio of the specialized prescaler.
Inputs the signal to select the device.
To operate the PLL and IDC, set the input signal
high.
If the input signal is low, the device can be backed
up with a low current drain by executing a stop
instruction.
When the input signal goes high, the device is reset
and the program is started from address 0.
Used to connect a crystal.
An 8-MHz crystal is used.
CMOS push-pull
—
N-ch open drain
—
—
CMOS tristate
—
CMOS push-pull
—
—
—
Undefined
Input
Undefined
—
Input
Hi-z
—
Undefined
Input
—
Input
