23.5 PERIPHERAL HARDWARE REGISTER
Symbol Attribute Value
Read/
Description
write
IDCORG DAT 01H R/W IDC start position setting register
ADCR DAT 02H R/W A/D-converter reference-voltage (V REF ) setting register
SIO0SFR DAT 03H R/W SIO0 register
HSC DAT 04H R Hsync counter data register
PWMR0 DAT 05H R/W PWM data register 0
PWMR1 DAT 06H R/W PWM data register 1
PWMR2 DAT 07H R/W PWM data register 2
PWMR3 DAT 08H R/W PWM data register 3
AR DAT 40H R/W Address register
PLLR DAT 41H R/W PLL data register
AR_EPA1 DAT 8040H – CALL/BR/MOVT instruction operand (EPA bit is on)
AR_EPA0 DAT 4040H – CALL/BR/MOVT instruction operand (EPA bit is off)
23.6 OTHERS
Symbol Attribute Value Description
DBF DAT 0FH Fixed operand value for a PUT/GET/MOVT instruction
IX DAT 01H Fixed operand value for an INC instruction
