16.4 WAIT REGISTER
The
µ
PD17062 can set a state in which the serial interface hardware does not operate, even if a shift clock
is input. This state is called wait mode and is set by the wait register.
The wait register consists of four bits; the SIO0WRQ0 flag, which specifies the timing to stop (wait) serial
interface communication, SIO0WRQ1 flag, SIO0NWT flag, which indicates if whether the current state is
waiting, and the SBACK flag, which indicates whether an acknowledgement is returned in two-wire bus mode.
The wait register, mapped to the register file, is manipulated by executing “PEEK” and “POKE” instructions
via the window register.
All flags of the wait register are reset to 0 at power-on reset and when the system clock is stopped by
executing a STOP instruction.
Fig. 16-4 Configuration of Wait Register
16.4.1 SIO0WRQ1 and SIO0WRQ0 (Serial I/O Wait Request) Flag
The SIO0WRQ1 and SIO0WRQ0 flags reserve (specify) the timing at which the serial interface hardware
is forced to wait. The
µ
PD17062 expands the concept of waiting from slave operations in two-wire bus mode,
to the transmission side in two-wire bus mode and internal clock operations in serial I/O mode.
During wait, the clock counter and the shift clock applied to the presettable shift register are disabled. This
means that, during wait, the clock counter is not updated and the contents of the presettable shift register
are not shifted, even if the level of the shift clock pin changes.
Bit position b 3 b 2 b 1 b 0
Flag name SBACK SIO0NWT SIO0WRQ1 SIO0WRQ0
