292
µ
PD17062
Name Description
APPENDIX DEVELOPMENT TOOLS
The following support tools are available for developing programs for the
µ
PD17062.
Hardware
The IE-17K, IE-17K-ET, and EMU-17K are in-circuit emulators applicable to the 17K
series.
The IE-17K and IE-17K-ET are connected to the PC-9800 series (host machine) or
IBM PC/AT TM through the RS-232-C interface. The EMU-17K is inserted into the
extension slot of the PC-9800 series (host machine).
Use the system evaluation board (SE board) corresponding to each product together
with one of these in-circuit emulators. SIMPLEHOST TM , a man machine interface,
implements an advanced debug environment.
The EMU-17K also enables user to check the contents of the data memory in real
time.
The SE-17002 is an SE board for the
µ
PD17002 and
µ
PD17062. It is used solely for
evaluating the system. It is also used for debugging in combination with the in-circuit
emulator.
The EP-17002CU is an emulation probe for the 48-pin shrink DIP (600 mil). It is used
to connect the SE board and the target system.
The EP-17002GC is an emulation probe for the 64-pin QFP (14
×
14 mm). It is used
with EV-9400GC-64 Note 3 to connect the SE board to the target system.
The EV-9200GC-64 is a conversion socket used to connect the EP-17002GC to the
target system.
In-circuit emulator
IE-17K
IE-17K-ET Note 1
EMU-17K Note 2
SE board
(SE-17002)
Emulation probe
(EP-17002CU)
Emulation probe
(EP-17002GC)
Conversion socket
(EV-9200GC-64 Note 3 )
Notes 1. Low-end model, operating on an external power supply
2. The EMU-17K is a product of IC Co., Ltd. Contact IC Co., Ltd. (Tokyo, 03-3447-3793) for details.
3. The EP-17002GC is supplied together with one EV-9200GC-64. A set of five EV-9200GC-64 is also
available.
