12.6 CAUTIONS IN USING THE TIMER INTERRUPT
In a program using a timer that operates at constant intervals once a power-on reset occurs, it is necessary
to have the timer interrupt handling routine finish within that constant interval.
This is explained using an example.
Example
BR AAA ; Branches to AAA after reset.
TIMER: ; Program address 0003H
ADD M1, #0100B ; Adds 0100B to the content of M1.
SKT1 CY ; Performs clock processing if a carry occurs.
BR AAA
; #
Clock process
EI
RETI
AAA:
INITFLG NOT BTM0ZX, NOT BTM0CK2, NOT BTM0CK1, NOT BTM0CK0
; Built-in macro
; Specifies the timer interrupt time and timer carry FF setting time interval as 250
and 100 ms, respectively.
SET1 IPBTM0 ; Built-in macro
EI ; Enables the timer interrupt.
Process A
BR AAA
The program in this example performs the clock process # at every one second while performing process
A.
If the CE pin goes from a low to a high as shown in Fig. 12-10 (a), a CE reset occurs in synchronization with
the positive-going edge of the timer carry FF set pulse. If the timer interrupt request happens to be issued
simultaneously when the timer carry FF is set, a CE reset takes precedence. When the CE reset occurs, it resets
the timer interrupt request (IRQBTM0 flag), thus skipping the timer process once.
