400
Field Description
Downlink CAC packets Number of downlink CAC packets.
Downlink CAC bytes Number of downlink CAC bytes.
Downgrade packets Number of downgraded packets.
Downgrade bytes Number of downgraded bytes.
Discard packets Number of dropped packets.
Discard bytes Number of dropped bytes.
Setting rate limiting
The WLAN provides limited bandwidth for each AP. Because the bandwidth is shared by wireless clients
attached to the AP, aggressive use of bandwidth by a client will affect other clients. To ensure fair use of
bandwidth, rate limit traffic of clients in either of the following approaches:
• Configure the total bandwidth shared by all clients in the same BSS. This is called "dynamic mode".
The rate limit of a client is the configured total rate/the number of online clients. For example, if the
configure total rate is 10 Mbps and five clients are online, the rate of each client is 2 Mbps.
• Configure the maximum bandwidth that can be used by each client in the BSS. This is called "static
mode". For example, if the configured rate is 1 Mbps, the rate limit of each user online is 1 Mbps.
When the set rate limit multiplied by the number of access clients exceeds the available bandwidth
provided by the AP, no clients can get the guaranteed bandwidth.
To set rate limiting:
1. Select QoS > Wireless QoS from the navigation tree.
2. Click the Client Rate Limit tab.
3. Click Add to enter the page for setting rate limiting.
Figure 424 Setting rate limiting
4. Set rate limiting as described in Table 134 .
5. Click Apply.
Table 134 Configuration items
Item Description
Wireless Service Display an existing wireless service.
