158
NOTE:
•
The PC where you configure the device is not necessarily the web-based network management terminal.
A web-based network management terminal is a PC (or another terminal) used to log in to the web
interface and is required to be reachable to the device.
• After logging in to the web interface, you can create a new user and configure the IP address of the
interface connecting the user and the device.
• If you click the verification code displayed on the web login page, you can get a new verification code.
• Up to 5 users can concurrently log in to the device through the web interface.
Logging out of the web interface
As shown in Figure 164 , click Logout in the upper-right corner of the web interface to quit web-based
network management.
The system does not save the current configuration before you log out of the web interface. H3C
recommends you to save the current configuration before logout.
CAUTION:
A logged-in user cannot automatically log out by directly closing the browser.
Introduction to the web interface
The web interface is composed of three parts: navigation tree, title area, and body area, as shown
in Figure 164 .
Figure 164 Web-based configuration interface
(1) Navigation area (2) Body area (3) Title area
• Navigation area—Organizes the web-based NM function menus in the form of a navigation tree,
where you can select function menus as needed. The result is displayed in the body area. The Web
network management functions not supported by the device are not displayed in the navigation
area.
• Body area—The area where you can configure and display a function.
