394
3. Configure SVP mapping as described in Table 126 .
4. Click Apply.
Table 126 Configuration items
Item Description
Radio Displays the selected radio.
SVP Mapping
Select the option before SVP Mapping, and then select an access category for
the SVP service:
• AC-VO.
• AC-VI.
• AC-BE.
• AC-BK.
Setting CAC admission policy
1. Select QoS > Wireless QoS from the navigation tree.
By default, the QoS Service tab is displayed.
2. Click the icon for the desired radio to enter the page for setting CAC admission policy.
Figure 419 Setting CAC admission policy
3. Configure the CAC admission policy as described in Table 127 .
4. Click Apply.
Table 127 Configuration items
Item Description
Client Number
Users-based admission policy, or the maximum number of clients allowed to
be connected. A client is counted only once, even if it is using both AC-VO and
AC-VI.
By default, the users-based admission policy applies, with the maximum
number of users being 20.
Channel Utilization
Channel utilization-based admission policy, or the rate of the medium time of
the accepted AC-VO and AC-VI traffic to the valid time during the unit time.
The valid time is the total time during which data is transmitted.
Setting radio EDCA parameters for APs
1. Select QoS > Wireless QoS from the navigation tree.
