8

Figure 6 RADIUS configuration page

4.

Configure the parameters as described in

Table 7

.

Table 7 Configuration items

Item Description

Service Type

Select the type of the RADIUS server.
Two types are available: standard and enhanced:

extended—Specifies extended RADIUS server, which is usually an iMC server.

In this case, the RADIUS client (access device) and the RADIUS server exchange

packets based on the specifications and packet format definitions of a private

RADIUS protocol.

standard—Specifies the standard RADIUS server. In this case, the RADIUS

client (access device) and the RADIUS server exchange packets based on the

specifications and packet format definitions of the standard RADIUS protocols
(RFC 2138, RFC 2139, and the updates).

Authentication IP

Enter the IP address of the RADIUS authentication server.

Authentication UDP Port

Enter the port number of the RADIUS authentication server.

Authentication Key

Enter the shared key of the RADIUS authentication server.

Accounting IP

Enter the IP address of the RADIUS accounting server.

Accounting UDP Port

Enter the port number of the RADIUS accounting server.

Accounting Key

Enter the shared key of the RADIUS accounting server.
