Chapter 4 Parameters|

Revision Nov. 2008, VLE1, SW V1.03 4-43

Control Mode

Settings

VF

VFPG

SVC

FOCPG TQCPG FOCPM

2: Operation speed attained

3: Desired frequency attained 1 (Pr.02-25)

4: Desired frequency attained 2 (Pr.02-27)

5: Zero speed (frequency command)

6: Zero speed with stop (frequency command)

7: Over torque (OT1) (Pr.06-05~06-07)

8: Over torque (OT2) (Pr.06-08~06-10)

9: Drive ready

10: User-defined Low-voltage Detection (LV)

11: Malfunction indication

12: Mechanical brake release (Pr.02-29, Pr.02-30)

13: Overheat (Pr.06-14)

14: Brake chopper signal

15: Motor-controlled magnetic contactor output

16: Slip error (oSL)

17: Malfunction indication 1

18:

Reserved

19: Brake chopper output error

20: Warning output

21: Over voltage warning

22: Over-current stall prevention warning

23: Over-voltage stall prevention warning

24: Operation mode indication (Pr.00-15≠0)

25: Forward command

26: Reverse command

27: Output when current >= Pr.02-33

28: Output when current < Pr.02-33

29: Output when frequency >= Pr.02-34

30: Output when frequency < Pr.02-34

31-32:

Reserved

33: Zero speed (actual output frequency)

34: Zero speed with Stop (actual output frequency)

35:

Fault output option 1 (Pr.06-22)

36: Fault output option 2 (Pr.06-23)

37: Fault output option 3 (Pr.06-24)

38: Fault output option 4 (Pr.06-25)

39:

Reserved

40: Speed attained (including zero speed)

41:

Reserved


Settings

Functions

Descriptions

0 No

Function

1

AC Drive Operational

Active when there is an output from the drive or RUN
command is ON.

2 Operation

speed

attained

Active when the AC motor drive reaches the output frequency
setting.
