Chapter 4 Parameters|
4-32 Revision Nov. 2008, VLE1, SW V1.03
01-12 Accel. Time 1 Unit: 0.01
01-14 Accel. Time 2 Unit: 0.01
01-16 Accel. Time 3 Unit: 0.01
01-18 Accel. Time 4 Unit: 0.01
Control
mode
VF VFPG SVC FOCPG FOCPM
Factory setting: 3.00
Settings 0.00~600.00 sec
01-13 Decel. Time 1 Unit: 0.01
01-15 Decel. Time 2 Unit: 0.01
01-17 Decel. Time 3 Unit: 0.01
01-19 Decel. Time 4 Unit: 0.01
Control
mode
VF VFPG SVC FOCPG FOCPM
Factory setting: 2.00
Settings 0.00~600.00 sec
01-20 JOG Acceleration Time Unit: 0.01
01-21 JOG Deceleration Time Unit: 0.01
Control
mode
VF VFPG SVC FOCPG FOCPM
Factory setting: 1.00
Settings 0.00~600.00 sec
The Acceleration Time is used to determine the time required for the AC motor drive to ramp
from 0Hz to Maximum Output Frequency (Pr.01-00).
The Deceleration Time is used to determine the time require for the AC motor drive to
decelerate from the Maximum Output Frequency (Pr.01-00) down to 0Hz.
The Acceleration/Deceleration Time 1, 2, 3, 4 are selected according to the Multi-function Input
Terminals settings. The factory settings are acceleration time 1 and deceleration time 1.
The larger against torque and inertia torque of the load and the accel./decel. time setting is
less than the necessary value, it will enable torque limit and stall prevention function. When it
happens, actual accel./decel. time will be longer than the action above.
